WASP

Features

• Ultra-small 2D scan head
• Beam entrance nearly centered to scan head width
• Aperture 6 mm
• For wavelength 1020 – 1080 nm

WASP

DRAGONFLY

Features

• Ultra-small 2D scan head
• Virtually no displacement between beam entrance and beam exit
• Internal beam expander (available with magnification 3× to 8×)
• Internal pilot laser
• Aperture 6 mm
• For wavelength 1020 – 1080 nm

DRAGONFLY

COLIBRI

Features

• Compact 2D scan head
• Aperture 6 or 11 mm
• For all commercial wavelengths

COLIBRI

SQUIRREL

Features

• Compact 2D scan head
• Aperture 6 or 11 mm
• For all commercial wavelengths

SQUIRREL

RACOON

Features

• standard 2D scan head
• aperture 11, 16 or 21 mm
• for all commercial wavelengths

RACOON

RACOON S

Features

• high performance heavy duty 2D scan head
• best dynamic axis matching for high trepanning frequencies
• aperture 8.5s or 11s mm
• for wavelength 355, 1020 – 1080 or 10600 nm

RACOON S

RHINO

Features

• heavy duty 2D scan head
• suitable for measurement systems, multi-kW applications and gas lasers
• available in a version without an objective, e. g. for annealing
• aperture 16, 21, 31/28 or 31 mm
• for all commercial wavelengths

RHINO

RHINO S

Features

• high performance heavy duty 2D scan head
• best dynamic axis matching for high trepanning frequencies
• aperture 8.5s, 11s or 26s mm
• for wavelength 355, 1020 – 1080 or 10600 nm

RHINO S

FIBER RHINO

Features

• heavy duty 2D scan head for fiber lasers
• suitable for vision and measurement systems, multi-kW applications and gas lasers
• fiber coupling: Optoskand QBH, Type D, clamp for collimated fiber output Ø 30 or 35 mm, or others on request
• fiber collimator with 80, 100, 120,150,170 or 200 mm focal length
• aperture 16, 21, 31/28 or 31 mm
• fo wavelength 1020 – 1080 nm

FIBER RHINO
